1.One half of the energy saving, the power consumption of comparable products;
2.The fully enclosed design to prevent dust from entering; changed the oil spills around the phenomenon of domestic bending machine, the overall appearance of the level of foreign. Easy maintenance, high efficiency, long life and environmental effects.
3.Steel welded structure, equipment rigidity, and computer finite element analysis to optimize the design calculation;
4 axis roll medium carbon after forging and quenched and tempered, finishing;
5. Electric centralized control, the operation is simple and convenient;
6. Integration technology, improve product reliability. Preferred famous domestic manufacturers of major components;
7 console humanity Chinese design, easy to operate and convenient;

NO.	ITEMS		PARAMETER	UNIT	REMARK
1	model		W11-12×2500	1set
2	Max thickness of Steel Plate		12	mm
3	Max width of roll board		2500	mm
4	Plate Speed		5.8	m/min
5	Full Loading Diameter of Coiled Plate		650	mm
6	Up roll diameter		240	mm
7	Down roll diameter		220	mm
8	Main Motor Power		15	kw
9	Size	L	4550	mm
W	1350	mm
H	1610	mm
10	Weight		7100	kg
