1) The machine employs hydraulically-driven swing beam, the steel plate welded structure,
and accumulator -based pullback cylinder with steady and reliable operation.
2) Indicator-based adjustment of gap of blade is convenient and fast. 3) The machine is equipped with lighting alignment device, and uses stepless control
for the stroke of up tool carrier.
4) The machine uses protection fence for safe operation.
5) Digital display device for size of back gauge and shearing times available

NO.	ITEMS		PARAMETER	UNITS	REMARK
1	Model		QC12Y-12X3200	1
2	Shearing thichness		12	mm
3	Shearing Width		3200	mm
4	Travel Times		10	min-1
5	Shearing Angler		1°40′	°
6	Backgauge Distance		20-600	mm
7	Main Motor Power		18.5	kw
8	Size	L	3900	mm
		W	2127	mm
		H	2235	mm
9	Weight		11600	kg
